• 60/40 flip-up rear split bench seat
• AM/FM stereo w/clock
• Black ring w/black vanes air conditioning registers
• Black urethane steering wheel
• Black vinyl floor covering (N/A w/47R Floor Mats)
• Display center -inc: warning messages & text functions
• Driver & front passenger door scuff plates
• Floor console cupholder
• Front passenger side A-pillar grab handle
• Front pwr point
• Instrument panel mounted cigar lighter
• Manual air conditioning
• Rear door cupholders
• Rear pwr point
• SecuriLock anti-theft ignition (PATS)
• Sunvisors w/driver side strap, passenger mirror
• Tilt steering column
• Vinyl 40/20/40 split bench front seat

• (4) pickup box tie-down hooks
• 2-ton jack
• 6.5' pickup box
• 6700# GVWR, 1610# maximum payload
• 78-amp/hr (750CCA) maintenance-free battery
• Easy Fuel capless fuel filler system
• Gas shock absorbers
• Leaf spring rear suspension w/2-stage variable rear springs
• Long-spindle double wishbone front suspension w/coil-over-shock IFS
• Pwr front/rear disc brakes
• Pwr rack & pinion steering
• Rear wheel drive
• Trailer sway control

• 3-point safety belts at all rear seat positions
• AdvanceTrac w/roll stability control (RSC)
• Anti-lock braking system (ABS)
• Auto lock safety belt feature for child seats
• Center front 2-point safety belt
• Dual note horn
• Dual stage driver & front passenger seat-mounted side airbags
• Dual stage driver & passenger front airbags w/passenger off switch
• Outboard front lap & shoulder safety belts -inc: height adjusters, pretensioners, energy management retractors
• Rear door child safety locks
• Safety Canopy front/rear outboard side curtain airbags
• SOS post crash alert system
• Tire pressure monitoring system

3.7L V6 FFV ENGINE

• (STD)

• Rear Wheel Drive
• Power Steering
• 4-Wheel Disc Brakes
• Tires - Front All-Terrain
• Tires - Rear All-Terrain
• Steel Wheels
• Conventional Spare Tire
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• AM/FM Stereo
• Vinyl Seats
• Split Bench Seat
• Pass-Through Rear Seat
• Rear Bench Seat
• Adjustable Steering Wheel
• Immobilizer
• A/C
• Power Outlet
• Power Outlet
• Passenger Vanity Mirror
• ABS
• Traction Control
• Stability Control
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch
• Front Side Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Child Safety Locks
• Tire Pressure Monitor

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.7 x 9.1
• Rear Brake Rotor Diam x Thickness (in): 13.7 x 9.0
• Cargo Area Dimensions
• Cargo Box (Area) Height (in): 22.4
• Cargo Box Length : Floor (in)
• Cargo Box Width : Floor (in)
• Cargo Box Width : Top, Rear (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume (ft³): 65.5
• Ext'd Cab Cargo Volume (ft³): 40.9
• Tailgate Width (in): 60.3
• Cooling System
• Total Cooling System Capacity (qts): 15.0
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 155
• Maximum Alternator Watts: 2100
• Emissions
• EPA Greenhouse Gas Score: 3
• Tons/yr of CO2 Emissions : 15K mi/year
• Exterior Dimensions
• Front Bumper to Back of Cab (in): 153.0
• Ground to Top of Load Floor (in): 33.8
• Height, Overall (in): 75.2
• Length, Overall w/o rear bumper (in): 231.8
• Overhang, Front (in): 38.3
• Wheelbase (in): 144.5
• Width, Max w/o mirrors (in): 79.2
• Frame
• Frame Type: Fully-boxed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: Midship
• Interior Dimensions
• Front Head Room (in): 41.0
• Front Hip Room (in): 60.5
• Front Leg Room (in): 41.4
• Front Shoulder Room (in): 65.9
• Passenger Capacity: 6
• Second Head Room (in): 39.7
• Second Hip Room (in): 65.4
• Second Leg Room (in): 33.4
• Second Shoulder Room (in): 65.7
• Mileage
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 23
• Fuel Economy Est-Combined (MPG): 19
• Steering
• Steering Ratio (:1), At Lock: 20.0
• Steering Ratio (:1), On Center: 20.0
• Steering Type: Pwr Rack & Pinion
• Turning Diameter - Curb to Curb (ft): 47.0
• Summary
• Body Code: 145" WB
• Body Style: SuperCab Pickup
• Vehicle Name: Ford F-150
• Suspension
• Axle Capacity - Front (lbs): 3750
• Axle Capacity - Rear (lbs): 3500
• Axle Ratio (:1) - Rear: 3.73
• Axle Type - Front: Double Wishbone
• Axle Type - Rear: Semi-Floating
• Shock Absorber Diameter - Front (mm): 36.1
• Shock Absorber Diameter - Rear (mm): 32.0
• Spring Capacity - Front (lbs): 3450
• Spring Capacity - Rear (lbs): 3800
• Stabilizer Bar Diameter - Front (in): 1.34
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: Leaf Spring
• Tires
• Front Tire Order Code: T7B
• Front Tire Size: P235/75R17
• Rear Tire Order Code: T7B
• Rear Tire Size: P235/75R17
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Spare Tire Order Code: T7B
• Spare Tire Size: P235/75R17
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1450
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 5800
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 870
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 5800
• Weight Information
• Curb Weight - Front (lbs): 2884
• Curb Weight - Rear (lbs): 2159
• Gross Axle Wt Rating - Front (lbs): 3450
• Gross Axle Wt Rating - Rear (lbs): 3800
• Gross Combined Wt Rating (lbs): 11100
• Gross Vehicle Weight Rating Cap (lbs): 6700
• Wheels
• Front Wheel Material: Steel
• Front Wheel Size (in): 17 x 7.5
• Rear Wheel Material: Steel
• Rear Wheel Size (in): 17 x 7.5
• Spare Wheel Material: Steel
• Spare Wheel Size (in): 17 x 7.5
